iCAD Assembler

Home

Designing with iCAD Assembler

our free CAD tool


Our construction tool iCAD Assembler offers the optimal supplement to our construction kit. Only with the combination of hard- and software complex requirements can be realized in a simple way - not only in rational mechanical engineering.

Your advantages:

  • 3D design tool for MiniTec components
  • Easy handling without CAD knowledge
  • Electronic catalog and configurators included
  • True to scale construction drawing and material parts list.
  • Direct interface to all common CAD systems like: Mechanical, Proengineer, Solid Works etc.
  • Integrated deflection analysis

System requirements:

  • IBM or compatible PC with min. 2GHz, 2GB RAM
  • Windows 8 | 10 | 11

Installation instructions depending on the download variant:

  • Exe.file: start setup.exe, follow the installation instructions and then start the program with ccAssembler.exe
  • Zip.file: unzip file on the PC and then start the program with ccAssembler.exe



Software iCAD Assembler
Free software download & more
License extension until 31.01.2027

The validity of the current iCAD Assembler license for software version 3.3.5 with the previous license renewal ends on January 31, 2026. Download the following file (1 KB) and save it on your computer to continue using iCAD Assembler. Please save it in the same directory where the “ccAssembler.exe” file is located. If you have already used the previous license extension, simply overwrite it when saving.

Download

iCAD Assembler (zip file)   (1 GB)
Download
iCAD Assembler (exe file)   (802 MB)
Download
iCAD Assembler   (2 MB)
Download
